ELITE MOTORIZE SCREEN

Projector Screen
Call Online Special price 03-8069 1655/ 03-8069 1755/ 012-278 5731 sales@3wiredsys.com
ELITE  MOTORIZED  SCREEN VMAX2 SERIES




VMAX 2 is an enhanced electric motorized projector screen for commercial and home theater applications. It has a silent and power-saving synchronous motor. With standard features such as the IR & RF remotes, 12v Trigger and Electronic “Eye” Receiver, the
VMAX 2 series
also includes Elite Screens GREENGUARD® Certified MaxWhite® and
MaxWhite® Fiberglass
materials that are ideal for large group presentations.

Screen Material:
    • MaxWhite® 1.1 Gain black backed material
    • MaxWhite® FiberGlass backed 1.1 Gain material, models 166" & below
    • 180° wide viewing angle
    • 4K Ultra HD, Active 3D, and HDR Ready
    • Not compatible with Ultra/Short-throw Projectors
    • Standard 4-side black masking borders
    • Matte White material is durable and easy to clean
    • Available in the following range of diagonal sizes:
      • 170" in 1:1 format
      • 120" - 165" in 4:3 format
      • 100" - 166" in 16:9 format
Elite Projector Screen


VMAX2 Series

For large cinema screen call for more details

elite projector screenSpectrum2 Series
ELITE MOTORIZED SCREEN
Premium Electric/ Motorized Projection Screen, Aluminium Housing with Wall/Ceiling Floating Bracket, MaxWhite FiberGlass Material, With On-Line Control Switch. Optional Remote Control Kit (ZPM-RT), Optional 3-Way Wall Switch (ZSP-WB-W)
MODEL
RATIO
NORMINAL DIAGONAL
VIEWING AREA - Height x Width
BLACK TOP (in)
FABRIC
GAIN
PRICE (RM)
cm
inch
 VMAX99XWS2
1:1
99"
177.8 x 177.8
70.0 x 70.0
2.0
MAX WHITE FG
1.1
1,960.00
 VMAX119XWS2
119"
213.4 x 213.4
84.0 x 84.0
2.0
2,450.00
 VMAX136XWS2
136"
243.8 x 243.8
96.0 x 96.0
2.0
2,590.00
 VMAX170XWS2
170"
304.8 x 304.8
120.0 x 120.0
2.0
3,850.00
VMAX100XWH2
16:9
100"
124.5 x 221.5
49.0 x 87.2
24.0
2,520.00
VMAX110XWH2
110"
137.2 x 243.8
54.0 x 96.0
24.0
2,660.00
VMAX120XWH2
120"
149.6 x 265.7
58.9 x 104.6
24.0
2,800.00
VMAX135XWH2
135"
168.1 x 299.0
66.2 x 117.7
24.0
3,780.00
VMAX150XWH2
150"
186.9 x 332.0
73.6 x 130.7
24.0
4,760.00
 VMAX106XWS2
16:10
106"
142.7 x 228.6
56.2 x 90.0
24.0
2,380.00
 VMAX128XWX2
128"
172.2 x 275.3
67.8 x 108.4
24.0
2,940.00
 VMAX142XWX2
142"
165.6 x 305.7
75.3 x 120.4
24.0
4,480.00
ELITE  MOTORIZED  SCREEN SPECTRUM2 SERIES



Spetrum 2 Series features premium white enamel coating aluminum casing with floating wall/ceiling brackets for easy installation. Elite's GREENGUARD Certified MaxWhite FG Screen material enhance picture viewing quality with wide viewing angle. Ideal for home or office use.
Screen Material:
  • MaxWhite™ FG (fiber-glass backing) 1:1 Gain
  • Screen material is flat, durable, easy to clean and mildew resistant
  • 180 degree wide-viewing angle for commercial and residential presentations
  • 4 side black masking borders enhance contrast ratio and absorbs projector overshoot
  • Black backing on material for sharper picture and clarity
  • 4K Ultra HD, Active 3D, and HDR Ready
  • Available in the following range of diagonal sizes:
  • 91"/ 100"/ 110" and 120" in 16:9 format
Elite Projector Screen


Spectrum2 Series

For large cinema screen call for more details

elite projector screenSpectrum2 Series
ELITE MOTORIZED SCREEN
Premium Electric/ Motorized Projection Screen, Aluminium Housing with Wall/Ceiling Floating Bracket, MaxWhite FiberGlass Material, With On-Line Control Switch. Wall and Ceiling installation, with IR & RF Remote and 3-way Wall Switch
MODEL
RATIO
NORMINAL DIAGONAL
VIEWING AREA - Height x Width
BLACK TOP (in)
FABRIC
GAIN
PRICE (RM)
cm
inch
SPM99S
1:1
99"
177.8 x 177.8
70.0 x 70.0
2.0
MAX WHITE FG
1.1
1,932.00
SPM90V-E24
4:3
90"
180.0 x 135.1
72.0 x 54.0
24.0
2,282.00
ELITE  MOTORIZED  SCREEN SPECTRUM SERIES
Elite Projector Screen


Spectrum Series

1 Year Standard Warranty for Motor

Screen Material:
    • MaxWhite™ material is durable and easy to clean
    • 180° wide viewing angle with 1.1 gain
    • Active 3D, 4K Ultra HD, and HDR Ready
    • Standard black masking borders
    • Also available in sound transparent material
    • Available in the following diagonal sizes:
            • 84", 100", 120" and 180" in 4:3 format
            • 84", 100", 110", 125", 150" and 180" in 16:9 format
            • 85", 90", 106", 128" and 142" in 16:10 format
            Spetrum Series motorized screen with MaxWhite 1.1 grain projection material gives better contrast and brighter picture from any angle.

            MaxWhite™ - Gain 1.1, 180° viewing angle
            MaxWhite™ screen material is the most versatile screen surface for front projection presentations. This material provides the widest possible viewer angles with perfect diffusion uniformity while giving precise definition, image color reproduction and black & white contrast. Recommended for rooms with controlled lighting. Works with Standard, Ultra/Short-throw 1080P/4K projectors.

            AcousticPro UHD - Gain 1.0, 180° viewing angle
            AcousticPro UHD is an acoustically transparent front projection screen. It is 4K ultra HD ready and moire-free from visual artifacts. Recommended for rooms with controlled ligthing. Works with Standard, Ultra/Short-throw 1080P/4K projectors.

            AcousticPro 1080P2 - Gain 1.0, 160° viewing angle
            AcousticPro1080P2 provides excellent color neutrality for superb color reproduction along with wide diffusion uniformity. The angular weave material is designed to allow wall-speaker sound to breathe through the screen while eliminating the visual artifact known as moiré effect. The material is perfect for use with native 1080P projectors.

            Elite Spectrum SeriesSpectrum Series
            ELITE MOTORIZED SCREEN
            Multi-Purpose Electric Screen, MaxWhite Screen Material, Wall/Ceiling Installation, with IR remote and 3-way Wall Switch and 12V Trigger.
            (OPTIONAL RF REMOTE CONTROL (ZSP-RF-W)
            MODEL
            RATIO
            NORMINAL DIAGONAL
            VIEWING AREA - Height x Width
            BLACK TOP (in)
            FABRIC
            GAIN
            PRICE (RM)
            cm
            inch
            Electric 119S
            1:1
            119"
            213.4 x 213.4
            84.0 x 84.0
            2.0
            MAX WHITE
            1.1
            2,100.00
            Electric 128NX-E24
            16:10
            128"
            172.2 x 275.3
            67.8 x 108.4
            24.0
            MAX WHITE
            1.1
            2,300.00
            ELITE  MOTORIZED  SCREEN  SAKER  SERIES

            Elite Projector Screen


            Saker Series

            1 Year Standard Warranty for Motor

            For large cinema screen call for more details
            Elite Spectrum SeriesSaker Series
            ELITE MOTORIZED SCREEN
            Enhanced Electric/Motorized Projection Screen, Aluminium Housing with Wall/Ceiling Floating Brackets, MaxWhite FiberGlass Material, InfraRed and Radio Frequency Remote, Wireless 12 Volt Trigger
            MODEL
            RATIO
            NORMINAL DIAGONAL
            VIEWING AREA- Height x Width
            BLACK TOP (in)/ CASE COLOUR
            FABRIC
            GAIN
            PRICE (RM)
            cm
            inch
             SK180XVW2-E12
            4:3
            180"
            274.3 x 365.8
            108.0 x 144.0
            12.0/ White
            MAX WHITE FG
            1.1
            9,520.00
             SK180XHW2-E12
            16:9
            180"
            223.0 x 398.5
            87.8 x 156.9
            10,080.00
             SK200XVW2
            4:3
            200"
            304.8 x 406.4
            120.0 x 160.0
            2.0/ White
            14,700.00
             SK235XVW2
            235"
            358.1 x 477.5
            140.3 x 187.0
            16,520.00
             SK265XVW2
            265"
            403.9 x 548.5
            159.0 x 212.0
            32,200.00
             SK200XHW2
            16:9
            200"
            249.1 x 442.8
            98.0 x 174.0
            14,700.00
             SK235XHW2
            235"
            293.1 x 520.7
            115.4 x 205.0
            16,520.00
             SK265XHW2
            265"
            330.2 x 587.0
            130.0 x 231.0
            32,200.00
            Elite Projector Screen
            Material

            • MaxWhite™ Fiberglass (1.1 Gain) matte white fiberglass-backed material
            • Wide viewing angle and uniformly diffuses light in all directions
            • Active 3D, 4K Ultra HD, and HDR Ready
            • Standard black masking borders and black screen backing
            • Available in the following range of diagonal sizes:
              • 84" - 150" in 16:9 format
              • 100" and 120" in 16:10 format

            Control System
            • Internal Radio Frequency/Infrared receivers with IR, RF remotes included
            • Detachable 3-way wall switch keypad for UP/STOP/DOWN manual operation
            • Wireless 5-12 volt trigger included
            • RJ45 port allows 3rd party control system integration
            The Saker Series is an electric projection screen that embodies all the virtues of quality, durability, and aesthetic value. It utilizes our MaxWhite™ Fiberglass (FG) material which has a wide viewing angle to allow the audience to see the image from anywhere in the room.  Standard features include a wireless 5-12 volt trigger, IR/RF remotes control package, and a detachable manual keypad switch.
            The enameled aluminum casing has a stylish arcuate profile that is best suited to the aesthetics of interior design. To make installation easy, the Saker comes fully assembled with sliding wall mounts to ensure that it will be properly centered in every installation.
            Elite Spectrum Series ELITE MOTORIZED SCREEN
            OPTIONAL REMOTE CONTROL
            MODEL
            DESCRIPTION
            PRICE (RM)
              ZPM-RT
             Remote control kit
            • IR Remote
            • RF Remote
            • 12V Trigger
            • IR Receiver
            • Wall Receiver Box
            		1,372.00
             ZSP-WB-W
            		  3-way Low Voltage Wall Switch266.00
             ZSP-RF-W/ ZSP-IR-W  RF or IR Remote Control266.00
